Mineral fillers for paint and coatings improve or influence technical and / or optical properties such as colour, hiding power and brightness. They are used to increase the volume, change the material density value and reduce the formulation costs of end customers. Other properties can be the anticorrosion protection in lacquers, influence of rheology in paints, increase scratch resistance and improve UV protection or flame-resistance of end products.
Rheology Performance | Physical Properties |
---|---|
|
|
ARTIC MIST®, CIMPACT®, JetWhite®, JetFill®, JetFill®M, MAGRIS TALC MISTRON®, NICRON®, SIERRALITE®, SILVERLINE®, STELLAR®, VERTAL®, YELLOWSTONE®
In the modern world of paint industry today, talc is more than a simple mineral filler. MAGRIS TALC offers highly lamellar talc products as well as microcrystalline and engineered types fine-grades reduced.
Bright white JETWHITE® und MISTRON® products as well as cost-effective NICRON® and SILVERLINE® products offer the laboratory developer a high degree of flexibility to balance the advantages of technical colour performance and improved process ability with rising raw material prices and higher production output.
Product | Form | Application | Benefits | D50 sedigraph | D98 sedigraph | Brightness [GEB] |
---|---|---|---|---|---|---|
JetWhite® 1H/HC | Natural white powder, submicron talc, bags | Additive for decorative paints, can coating | For maximum hiding power and brightness, TiO2 extender | 1.1 | ca. 6 (Hegman 7.5) | Y90 |
JetWhite® 7H/HC | Natural white powder, ultrafine talc, bags | Additive for decorative paints, can coating | For maximum hiding power and brightness, TiO2 extender | 1.9 | ca. 8 (Hegman 7) | Y91 |
NICRON® 665 | Natural white powder, microcrystalline talc, bags | Architectural and industrial primers and topcoats | Film strength and flexibility, provides barrier properties, very bright | 1.2 | ca. 9 (Hegman 6.5) | 87 |
MISTRON® MONOMIX | Natural white powder, micronzed talc, bags | Engineered and high performance, industrial and primers, protective coatings | High surface area and tight top-size control, anticorrosive functionality, rheology contribution | 2 | ca. 10 (Hegman 6) | 88 |
NICRON® 604 SILVERLINE® 604 | Natural white powder, microcrystalline talc, bags | Architectural and industrial primers and topcoats | Film strength and flexibility, provides barrier properties, improve corrosion resistance and stain-blocking ability | 2.3 | ca. 12 (Hegman 6) | 85 |
STELLAR® 510 | Natural white powder, lamellar talc, bags | Architectural and topcoats where high brightness is needed | Film strength and flexibility, provides barrier properties, very bright | 5 | ca. 15 (Hegman 5.5) | Y88 |
SILVERLINE® 504 | Natural white powder, microcrystalline talc, bags | Architectural and industrial primers, non-color sensitive applications | Improve corrosion resistance and stain-blocking ability, improve sag resistance and maximize prime pigment extension | 3.2 | ca. 20 (Hegman 5) | 81 |
NICRON® 403 MISTRON® 403 | Natural white powder, microcrystalline talc, bags | Architectural, wood and industrial primers and topcoats | Film strength and flexibility, provides barrier properties, semi-transparent wood stains to prevent tannin bleed, improve corrosion resistance and stain-blocking ability | 4.7 4.5 | ca. 25 (Hegman 4) | 83 86 |
JetWhite® 4H | Natural white powder, medium talc, bags | Decorative paints, architectural and industrial primers | Improve barrier properties which impart corrosion resistance and stain blocking ability | 5.7 | (Hegman 4-4.5) | Y90 |
VERTAL® 77 | Natural white powder, talc/carbonate mineral pigment, bags | Waterborne primers architectural and industrial, stain-blocking primers, sealers, undercoaters | Provides a unique balance of prime pigment spacing (opacity), film reinforcement, anti-cracking and barrier properties | 9 | ca. 25 | 78 |
NICRON® 303 | Natural white powder, microcrystalline talc, bags | Architectural, wood and industrial primers, also adhesive, sealant, caulk, joint compound, wood putty, and auto body patch applications | Film strength and flexibility, provides barrier properties, improve corrosion resistance and stain-blocking ability, good sandability | 7 | ca. 30 (Hegman 3) | 82 |
MISTRON® 303 NICRON® 302 | Natural white powder, microcrystalline engineered talc, bags | Protective coatings and marine coating applications, architectural flat exterior latex paints | Disperses easily in high-solids and solvent-borne coatings, good paint stability, rheology and anti-settling properties. Low sheen, good touch-up, good fade- and chalk-resistance | 7.5 13 | ca. 35 (Hegman 3) | 80 84 |
VERTAL® 92 | Natural white powder, talc/carbonate mineral pigment, bags | Auto Rep Grouts, Car Putties Autofill | Highly lamellar talc, macrocrystalline 200 Mesh, good sanding for abrasive paper use | 17.5 | ca. 45-50 | Y72 |
SILVERLINE® 202 | Natural white powder, microcrystalline engineered talc, bags | Airless-spray architectural waterborne flat paints | Engineered talc recommended where low viscosity build pigments are required, providing excellent sheen control, scrub resistance with minimal wear on airless spray equipment | 19.8 | ca. 50 (Hegman 2.5) | 76 |
JetWhite® 2H | Natural white powder, coarser talc, bags | Decorative paints, architectural and industrial primers | Improve barrier properties which impart corrosion resistance and stain blocking ability | 11 | ca. 60 (Hegman 2) | Y87 |
JetFil® M200 | Natural white powder, bags | General purpose applications for coarse talcs | High purity, platy, coarse talc | 10 | ca. 60 (Hegman 2) | Y78 |
SILVERLINE® 001 | Natural white powder, bags | Industrial floor screed, coarse filler | Concrete form lubricant, parting agent for rolled asphalt, roofing, floor tile | 14 | ca. 40 - 60 | off white |
VERTAL® AF | Natural white powder, UL Environment labeled for sustainability, only BB 2000 lbs | Construction, Bitumen Roofing, Flooring, Adhesives, Sound Damping | Talc with high magnesite content | 23 | 325 Mesh (44 µm) %passing 60-85 | off white |
MAGRIS Talc products are high-purity, functional additives ideal for putties and liquid compounds. Talc improves dimensional stabilityand reinforces putties and liquid compounds, giving added protection, against cracking and shrinking. Talc is the industry standard for sanding properties and polishing properties.
For putties and liquid compounds, adhesives and sealants we can offer also products from VERTAL® series with carbonic binding.
Applications | Physical Properties |
---|---|
|
|
Product | Form | Application | Benefits | D50 sedigraph | D98 sedigraph | Brightness [GEB] |
---|---|---|---|---|---|---|
NICRON® 302 | Natural white powder, bags | Sealants and Caulks, Pressure Sensitive and Structural Adhesives | High loading low viscosity, high brightness | 13 | ca. 30 (Hegman 3) | Y82 |
SILVERLINE® 303 | Natural white powder, bags | Pastes & Mastics, cementitious and self-leveling Compounds, fine | Finer top-size for smooth Finishes and application properties | 6,1 | ca. 40 | 78 |
VERTAL® 92 | Natural white powder, talc/carbonate mineral pigment, bags | Auto Rep Grouts, Car Putties Autofill | Highly lamellar talc, macrocrystalline 200 Mesh, good sanding for abrasive paper use | 17,5 | ca. 45 | Y72 |
VERTAL® 97 | Natural white powder, talc/carbonate mineral pigment, bags | Pastes & Mastics, cementitious and self-leveling Compounds | Highly lamellar talc, macrocrystalline 200 Mesh, good sanding for abrasive paper use | 15 | 50 | Y72 |
SILVERLINE® 002 | Natural white powder, bags | Pastes & Mastics, cementitious and self-leveling Compounds | High loading low viscosity | 8,4 | 55 | 75 |
VERTAL® TC-100 | Natural white powder, talc/carbonate mineral pigment, bags | Pastes & Mastics, cementitious and self-leveling Compounds | Improves resistance to cracking, smoothing and sandability, macrocrystalline 200 Mesh | 16,4 | 325 Mesh (44 µm) %passing 88 | off white |
VERTAL® AF | Natural white powder, UL Environment labeled for sustainability, only BB 2000 lbs | Construction, Bitumen Roofing, Flooring, Adhesives, Sound Damping | Talc with high carbonate (Mg) content, improved dimensional stability, cross-flow mechanical performance, and flexural stiffness | 23 | 325 Mesh (44 µm) %passing 60-85 | off white |
magris-talc-series---natural-talcs-for-putties-and-liquid-compounds,-adhesives-and-sealings.pdf
Talc is oleophilic which gives it the ability to associate with liquid resins such as alkyds, epoxies, polyesters, acrylics, amines and polyols. In doing so, they create weak bonds with these resins that result in increased low-shear viscosity. When shear is applied the bonds break quickly, resulting in shear-thinning rheology that is ideal for many applications.
OMEGA-SIL® are solid aluminium silicate spheres which have a very high compressive strength. The OMEGA-SIL® SPECIAL* product range consists of aluminium silicates that are processed in an additional processing step sifted. This particularly sharp separation of the top cut results in aesthetic applications to smoother surfaces.
Due to the lower specific surface the use of OMEGA-SIL® in paints and coatings allows a higher degree of filling. OMEGA- SIL® shows in cementitious systems pozzolanic reactivity. The inside microcrystalline structure results in a significant increase of mechanical strength.
Products | D50 [μm] | D95 [μm] | Effective density [g/cm³] | Bulk density [kg/m³] |
---|---|---|---|---|
OMEGA-SIL® XS | 3.5 | 9.5 | 2.51 | 780 |
OMEGA-SIL® S | 4.5 | 11.5 | 2.48 | 800 |
OMEGA-SIL® M | 6.5 | 30.0 | 2.40 | 870 |
OMEGA-SIL® L | 12.5 | 75.0 | 2.39 | 880 |
OMEGA-SIL® XL | 50.0 | 200.0 | 2.25 | 1,090 |
OMEGA-SIL® XS SPECIAL | 3.5 | 9.5* | 2.51 | 780 |
OMEGA-SIL® S SPECIAL | 4.5 | 11.5* | 2.48 | 800 |
OMEGA-SIL® M SPECIAL | 6.5 | 30.0* | 2.40 | 870 |
Product items shown with an asterisk * describe top cut (d98) modified versions for aesthetical surfaces.
The stated values correspond to typical values and hence do not represent a specification.
TRI-SPHERES® are hollow multi-cellular microspheres with a popcorn structure on a silicate basis. TRI-SPHERES® serve as functional lightweight fillers. Their heat resistance is up to 1,500 °C. Their compressive strength ends at 3,260 PSI / 22.5 Mpa. With a view to any shear forces occurring during the incorporation, their multi-cellular structure avoids that all spheres are destroyed at high forces. TRI-SPHERES® are marked by a clear bright colour.
TRI-SPHERES® can be used as lightweight fillers in many different applications such as paints and coatings, foams in composites as well as in hydraulic-setting cement for construction chemistry (TRI-SPHERES® 120 XL). With a view to the optimisation of acoustic and thermal properties, TRI-SPHERES® 270, 300 and 352 are recommended. In particular the fine TRI-SPHERES® 45XS Ultra achieves good results in partial weight reduction of PP polymer for injection mouldingwhen adding 10 – 15 % as an additive for the last step.
Products | D10 [μm] | D90 [μm] | Bulk density [kg/m³] | Crush strength [psi] | Effective density [kg/m³] |
---|---|---|---|---|---|
TRI-SPHERES® 120XL | 450 | 1.050 | 120 | < 725 | - |
TRI-SPHERES® 200 | 100 | 340 | 200 | < 725 | 440 |
TRI-SPHERES® 250 | 100 | 500 | 250 | - | 520 |
TRI-SPHERES® 270 | 150 | 350 | 270 | - | 580 |
TRI-SPHERES® 300 | 75 | 270 | 300 | 725 | 610 |
TRI-SPHERES® 352 | 115 | 275 | 350 | 1.030 | 800 |
TRI-SPHERES® 402 | 115 | 245 | 400 | 1.581 | 890 |
TRI-SPHERES® 450 | 75 | 230 | 450 | 2.176 | 720 |
TRI-SPHERES® 300S | 70 | 135 | 300 | 1.015 | 660 |
TRI-SPHERES® 400S | 75 | 160 | 400 | 1.421 | 690 |
TRI-SPHERES® 45XS ULTRA | 35 | 80 | 450 | 3.263 | 960 |
The stated values correspond to typical values and hence do not represent a specification.
tri-spheres©.pdfHollow ceramic microspheres are extremely resistant hollow spheres, which are formed under the exposure of extreme heat. Temperatures over the relevant melting points are required to achieve a ceramic melting. Drops with a hollow are formed as a result of the subsequent rapid cooling process. The OMEGA-SPHERES® formed in this way are refined and fractionated in subsequent processes, thus being a high-quality raw material in your formulations.
The spheres we provide are produced at various production sites for global availability. Globally produced standard types are manufactured in the Ukraine and Germany. Special types are produced in Germany. There are further suppliers in Europe and throughout the world.
OMEGA-SPHERES® are hollow ceramic microspheres > 150 μm which are used as functional lightweight filler is several industries. OMEGA-SPHERES® are characterised by a high thermal and mechanic resistance and are available in different distribution particle sizes.
Because of their weight-reducing and insulating properties, OMEGA-SPHERES® are used preferentially in construction chemical products such as adhesives and sealants. They are also used as pore generators in friction and brake linings as well as in grinding and separating tools.
Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
---|---|---|---|---|
OMEGA-SPHERES® 150 | 0 - 150 | 390 | 14 | 1,200 |
OMEGA-SPHERES® 300 | 0 - 300 | 400 | 14 | 1,200 |
OMEGA-SPHERES® SG | 0 - 500 | 400 | 14 | 1,200 |
OMEGA-SPHERES® G250-6 | 250 - 700 | 400 | 14 | 1,200 |
The stated values correspond to typical values and hence do not represent a specification.
omega-spheres®,-grey.pdfOMEGA-SPHERES® W are marked by a particularly high thermal resistance, low iron content and a white colour. They are available in different distribution particle sizes.
Because of their particularly high heat resistance, OMEGA-SPHERES® W are preferentially used in the refractory and foundry industries. The white colour allows their use in aesthetically demanding applications such as decorative plasters and wall paints.
Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
---|---|---|---|---|
OMEGA-SPHERES® W150 | 0 - 150 | 410 | 25 | 1,600 |
OMEGA-SPHERES® W300 | 0 - 300 | 410 | 25 | 1,600 |
OMEGA-SPHERES® WM | 150 - 300 | 390 | 25 | 1,600 |
OMEGA-SPHERES® W250-6 | 250 - 700 | 400 | 25 | 1,600 |
The stated values correspond to typical values and hence do not represent a specification.
omega-spheres®,-white.pdfTHERMO-SPHERES® G are high quality hollow ceramic microspheres < 150 μm, which are characterised by a high degree of fineness as well as a particularly high mechanical strength. The products are pre-dried. Because of the high fineness, they display good grinding properties and are, therefore, highly suitable as insulation and lightweight filling materials.
THERMO-SPHERES® G are used in applications which require the use of particularly small hollow microspheres or make high demands on surface finish. This includes, apart from the use in paints and coatings, composite materials, special casting compounds and putties, adhesives and sealants.
Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
---|---|---|---|---|
THERMO-SPHERES® G75 | 0 - 75 | 350 | 14 | 1,200 |
THERMO-SPHERES® G100 | 0 - 100 | 400 | 14 | 1,200 |
The stated values correspond to typical values and hence do not represent a specification.
thermo-spheres®,-grey.pdfTHERMO-SPHERES® W are white, high quality hollow ceramic microspheres < 150 μm, which are characterised by a high degree of fineness as well as a particularly high mechanical strength. The products are pre-dried and usable for foundry industry. The white colour allows their use in aesthetically demanding applications such as decorative plasters and wall paints.
THERMO-SPHERES® W are used in bright applications which require the use of the smallest possible microspheres or make high demands on surface quality. This includes applications in addition to the use in paints and coatings, surfaces as well as special casting compounds and adhesives where a high whiteness is advantageous.
Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
---|---|---|---|---|
THERMO-SPHERES® W100 | 0 - 100 | 400 | 25 | 1,600 |
THERMO-SPHERES® W125 | 0 - 125 | 400 | 25 | 1,600 |
The stated values correspond to typical values and hence do not represent a specification.
thermo-spheres®,-white.pdfOMEGA-BUBBLES® C are multicellular expanded glass granules. The high whiteness can help to reduce the addition of titanium dioxide in cementitious formulation. For aesthetic applications like acoustic construction or ceilings the ultra-white lightweight fillers meet today's spirit of time. OMEGA-BUBBLES® C being based on selected recycled glass. Using these products is sustainable and environmentally friendly and can reduces your green CO2 footprint in later disposal issues.
OMEGA-BUBBLES® C are available in the grain sizes customary on the market for the construction and insulation industry.
Products | Particle size range [mm] | Grain gross density [kg/m³] | Bulk density [kg/m³] |
---|---|---|---|
OMEGA-BUBBLES® C-XS | 0.1 - 0.3 | 680 - 920 | 340 - 460 |
OMEGA-BUBBLES® C-S | 0.25 - 0.5 | 460 - 620 | 255 - 345 |
OMEGA-BUBBLES® C-M | 0.5 - 1.0 | 380 - 510 | 210 - 290 |
OMEGA-BUBBLES® C-L | 1.0 - 2.0 | 310 - 420 | 190 - 250 |
OMEGA-BUBBLES® C-XL | 2.0 - 4.0 | 260 - 360 | 160 - 220 |
The stated values correspond to typical values and hence do not represent a specification.
omega-bubbles®-c-–-ultra-white.pdfLUVOFIL® TEC comprises a portfolio of multi-purpose functional fillers based on the world’s first polymer foam with pores in the nanometer range. Produced based on a patent-protected process and foamed with a 100% climate-friendly blowing agent, an entirely new class of materials with a pore size reduction of the factor 1000 compared to conventional polymer foams is provided leading to a unique and multi-purpose performance profile.
Products | Description | Particle Size D50 [µm] | Particle Size D100 [µm] | Application |
---|---|---|---|---|
LUVOFIL® TEC 50 | LUVOFIL® TEC 50 is a foamed, highly hydrophobic, thermoplastic polymer delivered as white powder with the lowest tamped density possible. | <15 | <50 | LUVOFIL® TEC 50 is used to achieve deep matting at highest transparency, anti-burnishing, mar, scratch, and scuff resistance, water repellency, water and chemical resistance, as well as water vapor permeability for water-based and solvent-free paints and coatings. Furthermore, LUVOFIL® TEC 50 is applied as matting and rheology control agent (fumed silica replacement) in SMP and silicone-based sealants. Applied as functional filler in cementitious and blow-in insulation systems as well as tile adhesives, LUVOFIL® TEC 50 offers weight reduction, thermal insulation and diffusion-open barrier properties. |
LUVOFIL® TEC 300 | LUVOFIL® TEC 300 is a foamed, highly hydrophobic, thermoplastic polymer delivered as white powder with the lowest tamped density possible. | <300 | LUVOFIL® TEC 300 is used as functional filler in order to provide weight reduction, thermal insulation and diffusion-open barrier properties in cementitious and blow-in insulation systems as well as tile adhesives. Furthermore, LUVOFIL® TEC 300 is applied as liquid carrier for powder coatings, masterbatches, and compounding with the ability to absorb more than 600 w% liquid depending on its chemical nature, polarity and viscosity. | |
LUVOFIL® TEC 1000 | LUVOFIL® TEC 1000 is a foamed, highly hydrophobic, thermoplastic polymer delivered as white powder with the lowest tamped density possible. | <1,000 | LUVOFIL® TEC 1000 is used as functional filler in order to provide weight reduction, thermal insulation and diffusion-open barrier properties in cementitious and blow-in insulation systems as well as tile adhesives. Furthermore, LUVOFIL® TEC 1000 is applied as liquid carrier for powder coatings, masterbatches, and compounding with the ability to absorb more than 600 w% liquid depending on its chemical nature, polarity and viscosity. |
luvofil®-tec-–-unique-class-of-multi-purpose-functional-fillers.pdf
